suspended scaffold platform

Basic Info Rated Load(Kg): 630,800,1000 Length of Working Platform: 6m,7.5m,7.5m Trademark: famous brand in China Transport Package: Carton Box Specification: ISO9001: 2000 Origin: Shanghai HS Code: 84289090 Product Description For the whole machine SPECIFICATION ZLP-1000 ZLP-800 ZLP-800A ZLP-630 ZLP-500 ZLP-250 Schedule Weight (Kg) 1000 800 800 630 500 250 Hoisting Speed (m/min) 8-10 8-11 8-11 9-11 9-11 8-11 Rated Power(kw) 3 2.2 1.8 1.5 1.5 1.1 Hoist LTD100 LTD80 LTD80A LTD63 LTD50 LTD40 Safety Lock LSF308 LSF308 LSF309 LSF308 LSF308 ...

Suspended Access Platforms/Work Platform Ce SCP350/23S 1. Description Aerial work platform s also called as mast climbing work platform, which is driven by motor and gear on rack, and moves up and down along the guiding mast. It is mainly composed of driving unit, chassis, mast sections, tripod deck, guardrails, tie-ins, electric control parts etc. And has the advantages such as no precast foundation, heavy lifting capacity, high working efficiency, wide working area, great security, etc. If can lift the ...

Basic Info Model NO.: many kinds Erection Position: External Scaffolding Move Method: Attached Lifting Scaffolding Scaffolding Part Type: Scaffolding Planks Construction Properties: Building Scaffold Rated Load: 100-1000kg Trademark: STRONG Transport Package: Wooden Case Specification: ZLP500~1000 Origin: Shanghai HS Code: 84313900 Product Description we can make the platform according to your special requirement Product Description: Suspended working platform is an ideal equipment for facade construction, decoration, cleaning and maintenance, and is also widely used in elevator installation, shipyard, big tank, bridge, ...

Product Description Suspended working platform is an ideal equipment for facade construction, decoration, cleaning and maintenance, and is also widely used in elevator installation, shipyard, big tank, bridge, embankment and chimney. It provides safer, easier and more efficient platform access For more details please contact us. ZLP series hoist suspended platform / swing stage 1. General Introduction for Suspended platform: ZLP series Suspended Platform is a substitute of traditional scaffold , it belongs to electrical-driven climbing and decorating machinery. 2 ...

Quick Details Place of Origin: Shanghai, China (Mainland) Brand Name: Success Model Number: ZLP HS Code: 8428909090 Name: Platform Crane Rated load: 630kg/800kg/1000kg Lifting Height: 200m Hoist Power: 1.5kw/1.8kw/2.2kw Hoist Voltage: 380V/415V/440V Cable: 200m Counterweight: 1000kg Lifting speed: 8-10 m/min Treatment: Hot galvanized Supply Ability Supply Ability: 5000 Set/Sets per Year Platform Crane Packaging & Delivery Packaging Details Platform Crane: 1-4sets/ one set for one wooden case-5cbm/set by LCL more than 5sets / packed on pallets by FCL 20'container for ...

Quick Details Place of Origin: China (Mainland), Shanghai,China Brand Name: Success Model Number: Scaffolding System, ZLP500/630/800/1000 Driving method: Electric power Name: suspended platform Type: ZLP series Materia: Aluminium/Steel/Zinc Voltage: 380V50HZ 3Phases Packaging & Delivery Selling Units: Single item Single volume:  4 cm 3 Single gross weight: 2000.0 KG Package Type: film protection from water and shock Steel Suspended Platform/Cradle/Swing Stage A kind of Temporarily Installed Suspended Access Equipment, also known as Suspended Platform or Temporary Access Equipment, is a lightweight ...

Product Description zlp series suspended platform is a new decorating machinery,which can repalce the traditional scaffold and have been used in many aspects,for example,exterior wall consruction,decoration, glass cleaning,ship building,bridge constrcution,chimney maintenance and repairing so on.Bacause the technology is mature,using balance suspeended platform can reduce work intensity and raise work efficiency, and it is easy to operate,so more and more people accept. The lentgh of the working platform is 5meters,which is made of two 2.5-mater platforms,the material is steel,and the surface ...

Product Description Working Principle of single person pedal suspended working platform Our single person pedal suspended working platform contains a suspension mechanism which can be set up on buildings. Driven by the hoist, the whole suspended platform will move up and down vertically along the steel ropes. Application Our single person pedal suspended working platform is an aerial working construction machinery used for curtain wall installing and exterior wall cleaning. This product is suitable for plastering, veneering, painting, cleaning and ...

Product Description high building suspended platform, construction cradle, gondola lift We are a factory specializing in the production of suspension platforms. Suspended platform is mainly composed by suspension mechanism, hoist, safety lock, electric control box, working platform.Its structure is reasonable and easy to operate.It can be assembled and disassembly accroding to the actual Demand.The cleaning platform is mainly used for refurbishment, decoration, cleaning and maintenance of high construction building. Platform accessories A.Features of ZLP Suspended Platform 1. Combination of the ...

Product Description Suspended platform is mainly composed by suspension mechanism,hoist,safety lock,electric control box,working platform.Its structure is reasonable and easy to operate.It can be assembly and disassembly accroding to the actual needs.The suspended platform is mainly used for refurbishment,decoration,cleaning and maintenance of high construction building. Model ZLP150 ZLP300 ZLP500 ZLP630 ZLP800 ZLP1000 Material Steel/Steel With Dipping Zinc/Aluminum Alloy Height 100m Rated load(kg) 150 300 500 630 800 1000 1000 Length of platform(m) 1.5 3.0 5.0 6.0 7.5 7.5 10.0 Safety lock ...

Quick Details Place of Origin: Shanghai, China (Mainland) Brand Name: success Model Number: ZLP630/800/1000 Lift Mechanism: Steel wire rope Lift Drive / Actuation: Electric Motor Power: 1.5kw/1.8kw/2.2kw Rated Loading Capacity: 630kg/800kg/1000kg Min. Lifting Height: 10m Max. Lifting Height: 120m Table Size: 6*0.72*1.3 Overall Dimensions: 3*1.1*1.2m Weight: 1800kg Certification: CE Certificate Warranty: 1 Year Supply Ability Supply Ability: 3000 Set/Sets per Year INSTRUCTION FOR ZLP SERIES 630 SUSPENDD PLATFORM Q1: What is the Warranty for suspended platform? A1: For suspended platform, ...

Introduction As professional manufacturer, we , success , only produce suspended platform with xinghe brand.Professional producing lines and technical team can supply you the best products and after-sales service. To confirm the quality of goods, we choose the best material, some spare parts of hosit and safety lock we cast our brand. With the unique design of wire rope clamping alarm device , it reduce the damage of hoist . When the wire rope is clamped , the alarm device ...

General Description Suspended platform consists if suspension mechanism,hoist,safety lock,electric control box and platform.They have resonable structure and they are easy to operate.According to the actual needs,they are arbitrarily assembled and disassembled.Suspended platfrom applies to exterior wall construction,decoration,cleaning and maintance of high-rise buildings. Suspended platfrom parameter Item type and parameter of suspended platform model of suspended platform ZLP 800 ZLP 630 lifting speed 8-10m/min 9-11m/min size of platform (lenght * width) (2.5mx3)x0.76m (2mx3)x0.76m steel wire rope structure：6x19W+1WS-8.3 Minimum breaking pull force：65KN ...

High Speed Suspended Access cradle scaffolding Platforms 2M x 2 Sections Property Model No. ZLP500 Rated load(kg) 500 Lifting speed(m/min) 9～11 Motor power(kw) 2×1.5 50HZ/60HZ Brake torque(Km) 16 Steel rope angle adjusting range(°) 3°- 8° Distance between two steel rope(mm) ≤100 Rated stretch of front beam(mm) 1500 Suspending platform Locking Aluminum alloy Nr.Of platform rack Single rack Nr.Of platform 2 L×W×H(mm) (2000×2)×690×1180 Weight(kg) 375 Kg Suspending mechanism(kg) 2×175 Kg Counterweight(kg) optional 25×30pcs Diameter of steel rope(mm) 8.3 Max Lifting height(m) ...

220v Single Phase Suspended Access Platforms ZLP800 Temporarily Suspended Scaffolding SUCCESS  brand ZLP Series suspended platform with unique top quality in the field of climbing and decorating machinery, which embody on excellent material, advanced design, refined manufacturing and good service. HAOKE make the most comprehensive models of suspended platform which with most wide range of applications in China. For example, specialized suspended platform for high-rise elevator shaft installation; granary and colliery security explosion-proof platform; dedicated platform for high-rise building tower ...

800KG Painted / Aluminum Suspended Access Platforms Motor Power 1.8KW Quick Detail: 1. Model No.: ZLP800 2. Brand Name: SUCCESS 3. Material: Steel / Aluminum 4. Appearance: Plastic Spray Painted / Hot Galvanized 5. Capacity Loading: 800 KG 6. Lifting Height: Maximum 300 Mts 7. Counterweight: Concrete, Concrete with Steel Cover, Iron (3 kinds optional) Applications: 1. Cleaning and maintaining of the exterior wall of high-rise building. 2. Painting, decoration and refurbishing of exterior walls. 3. Installation projects and other ...

Detailed Product Description Aluminium Alloy Suspended Working Platform / Cradle / Gondola / Scaffolding ZLP630 Our factory: SUCCESS is founded in 2005. It is a leading high-tech enterprise specialized in research, development and manufacturer of electrical suspended Platform, building hoist and other various kinds of construction equipments. Our products with professional quality, competitive price and fast delivery. We can customized according to your requirements. Applications 1. Widely used in construction, decoration, cleaning an maintenance of high-rise buildings. 2. Used in ...

Name Technical parameter Model ZLP800 ZLP630 Rated load 800Kg 630Kg Lifting speed 9-11m/min 1-11m/min Platform Dimension L×W×H(mm) 7500×690×1450 6000×690×1450 Lifting Height 100 m 100 m Cable 100 m 100 m Steel rope Ф9.1mm Ф8.3mm Hoist Power 1.8KW*2 1.5KW*2 Voltage 440V/50HZ 440V/50HZ Safety lock Permission force of impact 30KN 30KN Locking Cable Angle 3°~8° 3°~8° Suspension mechanism Front beam overhang 1.3~.1.5m 1.3~.1.5m Support adjustable height 1.44~2.14m 1.44~2.14m Counterweight 1000KG 1000KG 20’ft container 8 sets 9 sets Components and Projects: ...

Detailed Product Description Color: Red, Yellow, Green, Silver (can Be Customized) Material: Steel / Aluminum Alloy Finished: Painted / Hot Galvanized / Aluminum Motor Power: 2 X 1.8kw Voltage: 380V/415V/440V/220V, 50/60Hz (can Be Customized) Diameter Of Steel Rope: 8.6mm Motor Rotation Speed: 1420 R/min Counter Weight: Concrete, Concrete With Steel Cover, Iron-casting 2 x 1.8 kw Suspended Scaffolding Single Phase Suspended Platform Cradle ZLP800 HAOKE brand ZLP Series suspended platform with unique top quality in the field of climbing and ...

Detailed Product Description Ⅰ.Suspended Platform Identification Suspended platform is a kind of aerial working equipment for loading people, by setting up suspension frame on the top of building, which is using steel wire rope along building’s vertical surface,and making up and down movement depends on electrical power. Ⅱ.Main usages of suspended platform A)For exterior wall construction or decoration for tall building, or installing exterior components. B) FOR exterior wall maintenance and cleaning. C) For big project, for instance, construction, inspection ...
