SCP350/23S Suspended Access Work Platform
SCP350/23S Suspended Access Work Platform is a temporary access configuration for facade construction, cleaning, painting or maintenance where a roof-suspended system is appropriate. The final platform length, rated load, electrical supply and suspension arrangement should be confirmed for the actual project.
Suspended Access Platforms/Work Platform Ce SCP350/23S
1. Description
Aerial work platform s also called as mast climbing work platform, which is driven by motor and gear on rack, and moves up and down along the guiding mast. It is mainly composed of driving unit, chassis, mast sections, tripod deck, guardrails, tie-ins, electric control parts etc. And has the advantages such as no precast foundation, heavy lifting capacity, high working efficiency, wide working area, great security, etc. If can lift the passengers and goods exactly to the height needed, meanwhile allowing1-6 staff working on it. Mast climbing work platform suits for construction projects such as glass wall installation in air, outside wall decoration, celling installation and wire casing fixing work, because it work stable and safe, easy to install and replacing suspended platform and scaffolding platform in some areas.
Use and features
Length and width can be changed according to customer’s requirements.
Convenient for installation and movement
Overload device and auto balance device included
Synchronized running device
Emergency stop pushbuttons and travel limit switched
Constant speed safety device included to prevent the platform from sliding down over speed
Equipped with manual landing system, which allows the platform to be drive down manually while electric power off.
| Technical Data | |
| Platform Length Range | 8.1~23.1m |
| Platform Width | 1.5m |
| Max.Freestanding Height | 10m |
| Distance Between Anchors | 6m |
| Max. Height with Mast Anchored | 150m |
| Max.Mast Height Above Last Anchor | 3m |
| Max. Quantity of Passengers | 6 |
| Lifting Speed | 7m/min |
| Max.Loading Capacity | 3500kg |
| Mast Sections | 1.5m/90kg |
| Motor Power | 2*2*2.2KW |
| Supply Voltage | 3phase/380-415V |
Application
Facade work
Bricklaying
Balcony work
Window installation
Shipyard work
Bridge work
Basic Info
Certification: CE
Platform Length Range: 8.1~23.1m
Hoisting Speed: 7m/Min
Max Lifting Height: 150m
Max Freestanding Height: 10m
Motor Power: 2*2.2kw
Loder Weight: 3500kg
Rated Loading Capacity(Kg): 3500kg
After-Sales Service Provided: Engineers Available to Service Machinery Overseas
Delivery Detail: 30 Days After Tt in Advance or LC Confirmation
Trademark: SUCCESS
Transport Package: as Customized
Specification: CE, ISO9001
Origin: China, shanghai
Configuration and Applications
Model selection should consider the complete working load, platform section arrangement, building height, facade geometry and operating environment. A higher model rating does not allow the platform length or carried load to exceed the approved system limits.
Project Information Required
- Building height and required working length
- Workers, tools and material load
- Voltage, phase and frequency
- Roof parapet, suspension beam and counterweight conditions
Review our suspended access platforms, browse the product article library, or send the project requirements to Shanghai Success Construction International Trade Co., Ltd. Site planning should follow applicable local regulations and the OSHA suspended scaffold requirements.
